Modular Control Panel Enclosure
Modular double-door sheet metal enclosure with removable side panels for large control panel assemblies.
Material
Cold Rolled Steel (CRCA)
Tolerance
±0.3mm
Finish
Powder Coated (RAL 7035 Grey)
Size Range
800 x 600 x 2000mm to 1200 x 1000 x 2200mm (custom sizes available)
ISO 9001 Certified Ships to USA & Canada 24hr Quote Response
Product Overview
Our modular control panel enclosures feature removable side and rear panels, double hinged doors, and a bolt-together frame construction — allowing fast on-site assembly and easy access for panel builders working with large switchgear and automation systems.
Technical Specifications
| Material | 2mm CRCA Steel Frame, 1.5mm Panels |
| Protection Rating | IP54 |
| Door Type | Double hinged door, 3-point locking |
| Panels | Removable side and rear panels |
| Mounting | Internal 19" rails, adjustable depth |
Manufacturing Process
Laser cutting → CNC press brake forming → Frame welding → Powder coating → Modular assembly → 100% QC inspection
Applications
Large switchgear panels
Automation control cabinets
Motor control centers
Panel builder assemblies
Key Benefits
- Bolt-together modular frame for fast assembly
- Removable panels for easy internal access
- 3-point locking double door
- Adjustable internal mounting rails
Industries Served
ElectricalIndustrial AutomationOEM Panel BuildingRenewable Energy
Frequently Asked Questions
Can side panels be removed for internal access?
Yes, both side panels and the rear panel are fully removable for easy wiring and component access.
Do you supply panel-builder assemblies to drawing?
Yes, we manufacture to customer drawings including cutouts, gland plates, and mounting layouts.
